A range of new panel feed-throughs have been developed by Harting that feature robust metal housings for use with the company’s Han PushPull (variant 14 to IEC 61076-3-117): the standardised RJ45 connector to protection type IP 65/67 for industrial Profinet cabling.
The new feed-throughs are available for circular and square panel cut-outs for integration into industrial devices and switch cabinets.
A key feature of these new devices is their improved electromagnetic compatibility.
The category 6 performance of the RJ45 female module offers system reserves that are high enough to carry standard Industrial Ethernet and also 1/10 Gigabit Ethernet signals.
The RJ45 socket inserts have a 360° shield to increase electromagnetic compatibility and ensure interference immunity for the transmission path.
The feed-throughs allow easy fitting into devices and switch cabinets as well as retrofitting existing housings.
Users can choose from two RJ45 inserts. The RJ45 female model RJ Industrial Bulkhead Cat.6 (with two RJ45 connectors) enables routing of the Ethernet signal inside the device or switch cabinet with simple IP 20 patch cables.
The RJ45 cable socket Ha-VIS preLink allows easy and rapid build – pre-assembled or on site in the field.
Harting
