OKW has launched its pioneering new range of CONNECT enclosures for wired or USB electronics. CONNECT is aimed at electronics applications where the unit is connected to a cable, sits between cables or where the units are joined with USB connectors.
CONNECT is a two-piece enclosure with convex and flattened case shell sections. The flattened section is designed for fitting a membrane keypad or product label. Ergonomic rounded corners make it comfortable to hold.
Three sizes are available from launch: 54 mm x 22 mm in lengths of either 76, 116 or 156 mm.
The enclosures have open apertures at each end. They can be fitted with accessory end panels (which can be machined for USB connectors, LEDs) or integrated cable glands. The cable gland kits include a strain relief feature. Four fixing pillars inside the flattened case shell accommodate dia. 2.2 x 5 mm PCB screws.
Although CONNECT is designed for indoor use (IP 40), it is moulded from ASA+PC-FR (UL 94 V-0) for superior UV resistance. Other accessories include a holding clamp for round tubes up to dia. 32 mm.
Prices for CONNECT start at under £5. The enclosures can be supplied fully customised on request.
OKW Enclosures Ltd
Tel: 01489 583858
Web: www.okw.co.uk
