The range of modular Minitek127 systems from FCI’s is now available from TTI, Inc., This range of connectors are ideal for all types of wire to board and cable to board applications and includes straight and right angle, surface mount and through mount devices.  The connectors are fully intermateable with other common designs.

The devices offer a double row design, available in all sizes from 6 to 100 with copper alloy pins. Housings are halogen free, high-temperature black thermoplastic. Flammability rating is UL94V-0. This versatile system is available in different plating options, including gold and GXT over 50µ nickel.

Electrical specifications for the series are rated voltage 125VAC, maximum current rating 1A per contact continuous and dielectric withstanding voltage 500V.  Maximum contact resistance is 30m?.   Other technical specifications include an operating temperature range of -55degC to 125degC.  These devices are durable and can be mated to 100 cycles.

TTI, Inc.
